White (FDA) EPDM Rubber Sheet

Reglin White (FDA) EPDM is a premium grade 65 Duro food grade UV resistant rubber sheet.

FEATURES

Reglin White (FDA) EPDM Rubber Sheet is made from a premium EPDM rubber compound and will display high temperature and good chemical resistance to both acids and alkalis.

Reglin White (FDA) EPDM Rubber Sheet is tested and conforms to FDA 21 CFR 177.2600 “Rubber articles intended for repeated use”.  This makes it suitable for contact with dry, aqueous and fatty foods as defined by the FDA.

White (FDA) EPDM has good ozone/UV resistance making it weather resistant and suitable for outdoor use.  It has good physical properties including mechanical strength.

EPDM exhibits outstanding water resistance.   It is suitable for prolonged exposure to aquatic environments and will not deteriorate when submerged in fresh or sea water.  It is compatible with hot water and steam.

STANDARDS

White (FDA) EPDM conforms with FDA 21 CFR 177.2600.

As stated in FDA CFR 21.177.2600.  In accordance with good manufacturing practise finished rubber articles intended for repeated use in contact with food shall be thoroughly cleansed prior to their first use in contact with food.

APPLICATIONS

Reglin White (FDA) EPDM Rubber Sheet has been designed primarily for use as a flexible strip, pad, gasket or lining.

It is typically used for sealing, insulating, isolating and protecting steel or other surfaces.

White (FDA) EPDM is suitable for use in hygienic environments such as food and drink manufacturing, handling or storage facilities.  It is suitable for long term contact with dry or aqueous foods with UV exposure.

  • Flange gaskets on pipes and tanks
  • Lining of equipment
  • Transfer and joining sleeves
  • Bumper protection strips in food handling
  • Insulating strip
  • Isolation Barriers
  • Food grade skirting rubber
  • Non-marking load matting
  • Non-marking bearing pads
  • Variety of sealing applications

TECHNICAL INFORMATION

PolymerEPDM
Polymer Content 100%
Colour White
Specific Gravity1.25ASTM D297
Hardness65° ± 5° Shore AASTM D2240
Tensile Strength9 MPa (min)ASTM D412
Elongation @ Break350% (min)ASTM D412
Temperature Range-25°C to +110°C
Tear Strength20 N/mm (min)ASTM D624

AVAILABLE SIZES

Reglin stock White (FDA) EPDM Rubber Sheet in a range of standard thicknesses and roll sizes.   It can also be supplied in cut lengths, strips, pads and a wide variety of custom cut shapes and gaskets to suit your application requirements

PART NUMBERDESCRIPTIONPART NUMBER
WEPDM01.01400White (FDA) EPDM Rubber Sheet 1mm x 1400mm (10 L/M Rolls)2 kgs
WEPDM01.5White (FDA) EPDM Rubber Sheet 1.5mm x 1200mm (10 L/M Rolls)2.5 kgs
WEPDM03White (FDA) EPDM Rubber Sheet 3mm x 1200mm (10 L/M Rolls)5 kgs
WEPDM04.5White (FDA) EPDM Rubber Sheet 4.5mm x 1200mm (10 L/M Rolls)7.5 kgs
WEPDM06White (FDA) EPDM Rubber Sheet 6mm x 1200mm (10 L/M Rolls)10 kgs
WEPDM10White (FDA) EPDM Rubber Sheet 10mm x 1200mm (10 L/M Rolls)15.5 kgs
