T-Bolt Assemblies

High tensile, zinc coated steel T-Bolts designed for fastening industrial rubber products with T-Tracks

FEATURES

Our premium quality T-Bolts are manufactured from high-tensile Grade 8.8 steel machined from a single solid billet to provide ultimate strength and structural integrity. They provide excellent clamping force ensuring a secure and long-lasting connection, even in high-load and high-impact environments.

To protect against rust and corrosion, each T-Bolt is zinc-plated making them suitable for wet, abrasive or corrosive operating conditions commonly found in mining, quarrying and processing plants.

One key benefit of our T-Bolts is the speed and efficiency they offer during installation. They allow for fast mechanical fastening, significantly reducing downtime during liner replacement or maintenance.

T-Bolts are also removable and reusable, which means liners can be easily inspected, repositioned or replaced without damaging the fixings or equipment.

APPLICATIONS

Reglin T-Bolts are a high-performance mechanical fastening solution engineered specifically for securing bolt-on products featuring a T-Track.

They are widely used in mining, quarrying, materials handling and industrial processing applications where fast, reliable and low-maintenance installation is essential.

Our range of T-Bolts are designed to be fully compatible with standard T-Track designs featured in the following Reglin products:

This engineered compatibility ensures a seamless fit and a strong mechanical fastening between the product and the equipment surface.

AVAILABLE SIZES

We stock T-Bolt Assemblies in a range of standard sizes to suit Reglin Aluminium T-track designs. Each T-Bolt assembly includes a T-Bolt, flat washer and Nyloc nut.

Available in various thread sizes and lengths, our T-Bolts can be matched to suit various T-track designs and specific application requirements.

PART NUMBERDESCRIPTIONWEIGHT (EACH)
TBM124035T-bolt Assembly 35mm x 35mm Head M12 x 40mm
To suit AL-44 & AL-65 T-Tracks
0.12 kgs
TBM166035T-bolt Assembly 35mm x 35mm Head M16 x 60mm
To suit AL-44 & AL-65 T-Tracks
0.21 kgs
TBM169035T-bolt Assembly 35mm x 35mm Head M16 x 90mm
To suit AL-44 & AL-65 T-Tracks
0.23 kgs
TBM169050Heavy Duty T-bolt Assembly 50mm x 50mm Head M16 x 90mm
To suit AL-90 & AL-140 T-Tracks
0.35 kgs
